Setup/layout diagram of a 42m ringlock scaffold around a house.

House Pack: 42m Ringlock Scaffold, 1-Level

From: $10,436.32 + GST

42m Total Length x 0.73m Bay Depth x 3–3.5m Height
1 Level
20 Bays
Ringlock Modular Scaffolding System

For a video tour, scroll down.

House packs are customisable! Send us the measurements of your project/building, and we’ll design a scaffold specially for it, complete with 3D models.

Categories: , , ,

Base Jacks, Plates & Caster Wheels

Scaffolding screw jacks for sale in every variety!

From adjustable 600mm jack bases to 800mm adjustable base jacks – not to mention swivel jacks (which can be adjusted to any angle), plus castor wheels and more.

Whatever you need, you can select your solution below!

With New Zealand-wide delivery from our Auckland warehouse.

600 mm Adjustable Jack Base

Base Collar

Base Collar 250mm

Ringlock Diagonal Braces

0.73M×2.0M Ringlock Diagonal

Ringlock Diagonal Braces

3.07M×2.0M Ringlock Diagonal

Ledger "O"

Horizontal ledgers in any size.

"O"-type ringlock scaffolding.

Premium hot-dip galvanised steel for maximum durability and minimum corrosion.

Choose your sizing below!

0.73M Ringlock Ledger

Ledger "O"

Horizontal ledgers in any size.

"O"-type ringlock scaffolding.

Premium hot-dip galvanised steel for maximum durability and minimum corrosion.

Choose your sizing below!

2.07M Ringlock Ledger

Ledger "O"

Horizontal ledgers in any size.

"O"-type ringlock scaffolding.

Premium hot-dip galvanised steel for maximum durability and minimum corrosion.

Choose your sizing below!

3.07M Ringlock Ledger

Scaffolding Planks Steel (“O” Hook) Ringlock

Ready for an upgrade from flimsy, short-term wooden decks?

Check out these heavy-duty steel scaffold planks for sale.

These are "O" hook planks for the ringlock scaffolding system. Made with hot-dip galvanised steel for maximum durability and minimum corrosion.

320x76mm (1.5mm inner thickness).

Choose your length below!

0.73M×0.32(W)

Scaffolding Planks Steel (“O” Hook) Ringlock

Ready for an upgrade from flimsy, short-term wooden decks?

Check out these heavy-duty steel scaffold planks for sale.

These are "O" hook planks for the ringlock scaffolding system. Made with hot-dip galvanised steel for maximum durability and minimum corrosion.

320x76mm (1.5mm inner thickness).

Choose your length below!

2.07M×0.32(W)

Scaffolding Planks Steel (“O” Hook) Ringlock

Ready for an upgrade from flimsy, short-term wooden decks?

Check out these heavy-duty steel scaffold planks for sale.

These are "O" hook planks for the ringlock scaffolding system. Made with hot-dip galvanised steel for maximum durability and minimum corrosion.

320x76mm (1.5mm inner thickness).

Choose your length below!

3.07M×0.32(W)

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

1.5M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

2.0M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

2.5M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

3.0M Ringlock Standard with Spigot

Toeboards

0.73m x 0.15m

Toeboards

2.07m x 0.15m

Toeboards

3.07m x 0.15m

Description

Take a tour!

42m Total Length x 0.73m Bay Depth x 3–3.5m Height
1 Level
20 Bays
Ringlock Modular Scaffolding System

Components:
Base Jack 0.6m Adjustable | 40pcs
Base Collar | 40pcs
Diagonal Brace 0.73m | 4pcs
Diagonal Brace 3.07m | 4pcs
Horizontal Ledger 0.73m | 72pcs
Horizontal Ledger 2.07m | 24pcs
Horizontal Ledger 3.07m | 40pcs
Steel Deck 0.73m | 8pcs
Steel Deck 2.07m | 12pcs
Steel Deck 3.07m | 20pcs
Vertical Standard 1.5m | 4pcs
Vertical Standard 2m | 16pcs
Vertical Standard 2.5m | 4pcs
Vertical Standard 3m | 20pcs

Extras:
Steel Toeboard 0.73m | 8pcs | $137.20
Steel Toeboard 2.07m | 6pcs | $187.32
Steel Toeboard 3.07m | 10pcs | $408.30

Total Weight without Extras: 2519.8kg
Total Weight with Extras: 2682.98kg

Financing available.

House packs are customisable! Send us the measurements of your project/building, and we’ll design a scaffold specially for it, complete with 3D models.

Additional information

Base Jacks, Plates & Caster Wheels

Weight N/A
Dimensions N/A
Options

600 mm Adjustable Jack Base

Base Collar

Weight 1.72 kg
Dimensions 28 × 5.7 × 0.35 cm
Base Collar

Base Collar 250mm

Ringlock Diagonal Braces

Weight N/A
Dimensions N/A
Diagonal Options

0.73M×2.0M Ringlock Diagonal

Ringlock Diagonal Braces

Weight N/A
Dimensions N/A
Diagonal Options

3.07M×2.0M Ringlock Diagonal

Ledger "O"

Weight N/A
Dimensions N/A
Ledger Options

0.73M Ringlock Ledger

Ledger "O"

Weight N/A
Dimensions N/A
Ledger Options

2.07M Ringlock Ledger

Ledger "O"

Weight N/A
Dimensions N/A
Ledger Options

3.07M Ringlock Ledger

Scaffolding Planks Steel (“O” Hook) Ringlock

Weight N/A
Dimensions N/A
Steel Deck Options

0.73M×0.32(W)

Scaffolding Planks Steel (“O” Hook) Ringlock

Weight N/A
Dimensions N/A
Steel Deck Options

2.07M×0.32(W)

Scaffolding Planks Steel (“O” Hook) Ringlock

Weight N/A
Dimensions N/A
Steel Deck Options

3.07M×0.32(W)

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

1.5M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

2.0M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

2.5M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

3.0M Ringlock Standard with Spigot

Toeboards

Weight N/A
Dimensions N/A
Toe Boards Options

0.73M×0.15M, 1.09M×0.15M, 1.40M×0.15M, 1.57M×0.15M, 2.07M×0.15M, 2.57M×0.15M, 3.07M×0.15M

Toeboards

Weight N/A
Dimensions N/A
Toe Boards Options

0.73M×0.15M, 1.09M×0.15M, 1.40M×0.15M, 1.57M×0.15M, 2.07M×0.15M, 2.57M×0.15M, 3.07M×0.15M

Toeboards

Weight N/A
Dimensions N/A
Toe Boards Options

0.73M×0.15M, 1.09M×0.15M, 1.40M×0.15M, 1.57M×0.15M, 2.07M×0.15M, 2.57M×0.15M, 3.07M×0.15M
