2-in-1 Transforming Ringlock Scaffold: 2-Level 2.5m / 1-Level 5m

From: $1,650.76 + GST

Versatility is the name of the game with this transforming ringlock scaffolding package!

Two layouts for the price of one. Use it as a long single-storey scaffold or a tall two-storey build.

Mode 1:
2.57m Long x 0.73m Deep x 5m High
2 Levels
1 Bay

Mode 2:
5.14m Long x 0.73m Deep x 3m High
1 Level
2 Bays

Ringlock Modular Scaffolding System

Base Jacks, Plates & Caster Wheels

Scaffolding screw jacks for sale in every variety!

From adjustable 600mm jack bases to 800mm adjustable base jacks – not to mention swivel jacks (which can be adjusted to any angle), plus castor wheels and more.

Whatever you need, you can select your solution below!

With New Zealand-wide delivery from our Auckland warehouse.

600 mm Adjustable Jack Base

Base Collar

$8.58 + GST each

Ringlock Diagonal Braces

0.73M×2.0M Ringlock Diagonal

Ringlock Diagonal Braces

2.57M×2.0M Ringlock Diagonal

Ledger "O"

Horizontal ledgers in any size.

"O"-type ringlock scaffolding.

Premium hot-dip galvanised steel for maximum durability and minimum corrosion.

Choose your sizing below!

0.73M Ringlock Ledger

Ledger "O"

Horizontal ledgers in any size.

"O"-type ringlock scaffolding.

Premium hot-dip galvanised steel for maximum durability and minimum corrosion.

Choose your sizing below!

2.57M Ringlock Ledger

Scaffolding Planks Steel (“O” Hook) Ringlock

Ready for an upgrade from flimsy, short-term wooden decks?

Check out these heavy-duty steel scaffold planks for sale.

These are "O" hook planks for the ringlock scaffolding system. Made with hot-dip galvanised steel for maximum durability and minimum corrosion.

320x76mm (1.5mm inner thickness).

Choose your length below!

2.57M×0.32(W)

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

2.0M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Vertical standard for ringlock scaffolding.

Rosettes every 1/2 meter for maximum versatility.

Spigot built-in, for connecting multiple standards.

Made of premium hot-dip galvanised steel, for maximum durability and minimum corrosion.

3.0M Ringlock Standard with Spigot

Toeboards (L-Shaped)

0.73m x 0.15m

Toeboards (L-Shaped)

2.57m x 0.15m

Description

Versatility is the name of the game with this transforming ringlock scaffolding package! Two layout for the price of one. Use it as a long single-storey scaffold or a tall two-storey build.

Mode 1:
2.57m Long x 0.73m Deep x 5m High
2 Levels
1 Bay

Mode 2:
5.14m Long x 0.73m Deep x 3m High
1 Level
2 Bays

Ringlock Modular Scaffolding System

Components:
Base Jack 0.6m Adjustable | 6pcs
Base Collar | 6pcs
Diagonal Brace 0.73m | 2pcs
Diagonal Brace 2.57m | 2pcs
Horizontal Ledger 0.73m | 14pcs
Horizontal Ledger 2.57m | 8pcs
Steel Deck 2.57m | 4pcs
Vertical Standard 2m | 4pcs
Vertical Standard 3m | 4pcs

Extras:
Steel Toeboard 0.73m | 4pcs | $75.44*
Steel Toeboard 2.57m | 2pcs | $75.46*

Total Weight without Extras: 381.04kg
Total Weight with Extras: 408.22kg

Financing available.

Additional information

Base Jacks, Plates & Caster Wheels

Weight N/A
Dimensions N/A
Options

600 mm Adjustable Jack Base

Base Collar

Weight 1.72 kg
Dimensions 28 × 5.7 × 0.35 cm

Ringlock Diagonal Braces

Weight N/A
Dimensions N/A
Diagonal Options

0.73M×2.0M Ringlock Diagonal

Ringlock Diagonal Braces

Weight N/A
Dimensions N/A
Diagonal Options

2.57M×2.0M Ringlock Diagonal

Ledger "O"

Weight N/A
Dimensions N/A
Ledger Options

0.73M Ringlock Ledger

Ledger "O"

Weight N/A
Dimensions N/A
Ledger Options

2.57M Ringlock Ledger

Scaffolding Planks Steel (“O” Hook) Ringlock

Weight N/A
Dimensions N/A
Steel Deck Options

2.57M×0.32(W)

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

2.0M Ringlock Standard with Spigot

Ringlock Standard with Spigot

Weight N/A
Dimensions N/A
Standard Options

3.0M Ringlock Standard with Spigot

Toeboards (L-Shaped)

Weight N/A
Dimensions N/A
Toe Boards Options

0.73M×0.15M, 1.09M×0.15M, 1.40M×0.15M, 1.57M×0.15M, 2.07M×0.15M, 2.57M×0.15M, 3.07M×0.15M

Toeboards (L-Shaped)

Weight N/A
Dimensions N/A
Toe Boards Options

0.73M×0.15M, 1.09M×0.15M, 1.40M×0.15M, 1.57M×0.15M, 2.07M×0.15M, 2.57M×0.15M, 3.07M×0.15M

Transforming Ringlock Scaffold / Scaffolding Package, 2.5m Double Level, 5m Single Level
2-in-1 Transforming Ringlock Scaffold: 2-Level 2.5m / 1-Level 5m
From: $1,650.76 + GST
